Communications support modules
6-20 Hardware - SIMADYN D
Edition 12.2004
• If a fiber-optic cable is not inserted, the transmit- and receive connections
must be protected using the appropriate caps
• As CS13, CS14 of the ICS1 partial modules do not have a connector at
the L/C bus, when required, Daisy Chain jumpers must be inserted (if
there is still a CPU module to the right)!
• noise-immune operation is only possible if the module is tightly screwed
into the subrack
Further information on EMC and ambient conditions, refer to Section
"General technical data"
6.3.4 Technical data
No. of slots occupied CS12: 1
CS13: 2
CS14: 3
CS22: 1
Dimensions W x H x D [mm] CS12: 20.14 x 233.4 x 220
CS13: 40.28 x 233.4 x 220
CS14: 60.42 x 233.4 x 220
CS22: 20.14 x 233.4 x 220
Weight [kg] CS12: 0.5
CS13: 0.8
CS14: 1.1
CS22: 0.4
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V CS12: 1.8 A
CS13: 4.0 A
CS14: 5.5 A
CS22: 1.5 A
+15 V +14.4 V +15.6 V CS12: 50 mA
CS13: 100 mA
CS14: 150 mA
CS22: 150 mA
Other information
General data
Power supply
voltage
