Input/output modules
Hardware - SIMADYN D 5-13
Edition 12.2004
5
EB11
X5,X6
Significance SU12 SB10 SB60 SB61 SB70 SB71
21 Binary input 1 1 1/51 14,12/11 1,11/51
22 Binary input 2 2 2/52 24,22/21 2,12/52
23 Binary input 3 3 3/53 34,32/31 3,13/53
24 Binary input 4 4 4/54 44,42/41 4,14/54
25 Binary input 5 5 5/55 54,52/51 5,15/55
26 Binary input 6 6 6/56 64,62/61 6,16/56
27 Binary input 7 7 7/57 74,72/71 7,17/57
28 Binary input 8 8 8/58 84,82/81 8,18/58
29 External 24 V 9 1P 1P 1P
30 External ground 10 1M 1M 1M
Table 5-11 Terminal assignment, interface modules at SC13, cable end C
EB11
X5,X6
Significance SU12 SB10 SB60 SB61 SB70 SB71
31 Binary input 9 1 1/51 14,12/11 1,11/51
32 Binary input 10 2 2/52 24,22/21 2,12/52
33 Binary input 11 3 3/53 34,32/31 3,13/53
34 Binary input 12 4 4/54 44,42/41 4,14/54
35 Binary input 13 5 5/55 54,52/51 5,15/55
36 Binary input 14 6 6/56 64,62/61 6,16/56
37 Binary input 15 7 7/57 74,72/71 7,17/57
38 Binary input 16 8 8/58 84,82/81 8,18/58
39 External 24 V 9 1P 1P 1P
40 External ground 10 1M 1M 1M
Table 5-12 Terminal assignment, interface modules at SC13, cable end D
5.2.3 Application information and noise immunity
• operation without fan is possible
• noise-immune operation is only possible if the module is tightly screwed
into the subrack
Further information on EMC and ambient conditions, refer to Section
"General technical data"
Terminal
assignment at
SC13, end C
Terminal
assignment at
SC13, end D
