Technology subrack
7-12 Hardware - SIMADYN D
Edition 03.2001
Analog input 2
10 98
Ground, analog inputs and outputs 11 99
All grounds are connected mutually via inductivity and with electronics
ground.
The grounds connections of
 interfaces 1 and 2
 analog inputs/outputs
 binary inputs/outputs.
 incremental encoders 1 and 2
are connected to the T400 electronics ground through 0 Ohm resistors,
reactors and capacitors which can be soldered-out. For production-related
reasons, the 0 Ohm resistor is an SMD device (not separately connected)
and when required must be soldered-out (to interrupt the electrical
connection)!
7.2.9 Technical data
No. of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight approx. 0.6 kg
The T400 requires the following voltages at the upper backplane bus
connector X1:
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V 1000 mA
+15 V +14.4 V +15.6 V 140 mA + encoder load
(max. 100 mA, electronically limited)
-15 V -15.6 V -14.4 V 140 mA
24 V (external) 20 V 30 V 150 mA + binary output current
Note:
Grounding
General data
Power supply
