Technology subrack
Hardware - SIMADYN D 7-11
Edition 03.2001
7
T400 terminal assignment Con. Con.-pin Terminal
+ 24 V external (for binary inputs and outputs) X5 1 45
Bi-directional binary input and output 1 2 46
Bi-directional binary input and output 2 3 47
Bi-directional binary input and output 3 4 48
Bi-directional binary input and output 4 5 49
Ground, binary inputs and outputs 6 50
Binary output 1 7 51
Binary output 2 8 52
Binary input 1 (interrupt-capable) 9 53
Binary input 2 (interrupt-capable) 10 54
Binary input 3 (interrupt-capable) 11 55
Binary input 4 (interrupt-capable) X6 1 56
Binary input 5 2 57
Binary input 6 3 58
Binary input 7 4 59
Binary input 8 5 60
Ground, binary inputs and outputs 6 61
Encoder 2 : Track A ( HTL) Encoder 2: Track A+ ( RS422) 7 62
Encoder 2: Track B ( HTL) Encoder 2: Track B+ ( RS422) 8 63
Encoder 2: Zero pulse (HTL) Encoder 2: Zero pulse +
(RS422)
9 64
Encoder 2: Coarse pulse
10 65
Encoder 2 ground 11 66
Serial interface 1: Rx-RS232 X7 1 67
Serial interface 1: Tx-RS232 2 68
Serial interface ground 3 69
Serial interface . 1: Tx/Rx-RS485+ 4 70
Serial interface 1: Tx/Rx-RS485- 5 71
Serial interface 2: Rx-RS485+ Absolut-Encoder 2: Data+ 6 72
Serial interface 2: Rx-RS485- Absolut-Encoder 2: Data- 7 73
Serial interface 2: Tx (Rx)-RS485+ Absolut-Encoder 2: Pulse+ 8 74
Serial interface 2: Tx (Rx)-RS485- Absolut-Encoder 2: Pulse- 9 75
Absolut-Encoder 1: Data+ 10 76
Absolut-Encoder 1: Data- 11 77
Absolut-Encoder 1: Pulse+ X8 1 78
Absolut-Encoder 1: Pulse- 2 79
+ 15 V -Encoder Power Supply (max. 100 mA) 3 80
Increm.-Encoder 1: Track A 4 81
Increm.-Encoder 1: Track B 5 82
Increm.-Encoder 1: Zero pulse 6 83
Increm.-Encoder 1: Coarse pulse 7 84
Increm.-Encoder 1 Ground 8 85
Increm.-Encoder 2: Track A- (with RS422) 9 86
Increm.-Encoder 2: Track B- (with RS422) 10 87
Increm.-Encoder 2: Zero pulse- (with RS422) 11 88
Ground, analog inputs and outputs X9 1 89
Analog input 1 Analog input 1+ 2 90
Analog input 1- 3 91
Analog input 2 Analog input 2+ 4 92
Analog input 2- 5 93
Analog input 3 6 94
Analog input 4 7 95
Analog input 5 8 96
Analog input 1 9 97
