CPU module
Hardware - SIMADYN D 3-15
Edition 03.2001
3
3.2.1 Supplementary components
• MS5 and MS51 program memory modules
• Cable SC57 for PC connection, 9-core, 5 m
• Cable SC7 to connect an interface module, 10-core, 2 m
If additional input/output signals and other functions are required, then these
can be implemented by inserting a maximum of 2 expansion modules:
• IT41
• IT42
• ITDC
• ITSL
3.2.2 Application information and noise immunity
• Operation without fan is not possible
• Noise-immune operation is only possible if the module is tightly screwed
into the subrack
• Do not insert or withdraw the module when the subrack is powered-up
For more information regarding EMC and ambient conditions, refer to the
section "General technical data“!
3.2.3 Technical data
Number of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight approx. 0.51 kg
Rated voltage min. max. Typical current drain
+5 V +4.75 V +5.25 V 1700 mA
+15 V +14.4 V +15.6 V 50 mA
-15 V -15.6 V -14.4 V 30 mA
24 V (external) 20 V 30 V 100 mA + binary output currents
Other information
General data
Power supply
