Input/output modules
5-14 Hardware - SIMADYN D
Edition 12.2004
5.2.4 Technical data
No. of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight Approx. 0.6 kg
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V 420 mA
-15 V -15.6 V -14.4 V 20 mA (only as reference)
+24V +20 V +30 V 0,2 A (from an external power
supply)
+ current drain of the connected
SB70, SB71 interface modules
+ current drain from the binary
outputs which are directly
connected at the binary outputs of
the connected components (when
using SB10, SU11, SU12)
No. 2 x 16
Input voltage +24 V rated value
for 0 signal -1 V to +6 V; or open-circuit binary inputs
for 1 signal +13 V to +33 V
Input current for an 1 signal 5 mA typ.
Delay time 200 µs
No. 2 x 16
Power supply voltage
rated value +24 V DC
ripple 3.6 V DC
permissible
range
+20 to +30 V, including ripple
briefly +35 V for < 0.5 s
Output current for a 1 signal
rated value 50 mA
permissible
range
0.2 mA to 50 mA
Short-circuit protection Thermal / electronic
Limiting inductive switch-off
voltage
To the supply +1 V
Residual current 20 µA for a 0 signal
Signal level
for 0 signal Max. 3 V
for 1 signal Min. supply - 2.5 V
Delay time 15 µs
General data
Power supply
Binary inputs
Binary outputs
