Subracks
2-8 Hardware - SIMADYN D
Edition 04.2011
2.1.7 Technical data
AC power supply according to DIN IEC 38
Input voltage V
in
230 V (+ 10% / - 15%)
Input frequency 47.5 ... 62.5 Hz
Non-periodic overvoltages according to DIN VDE160, A5.3.1.1.2
Voltage 460 V
Duration 1.3 ms
Recovery time, min 0.1 s
Events per hour max. 10
Brief voltage dips according to DIN VDE 0160, A5.3.1.1.3
Voltage 0
Duration 5 ms
Recovery time, min 0.1 s
Events per hour max. 10
Output voltage 5 V
+5.1 V +/- 0.1 V
Output current
1.5 to 7 A
Ripple < 50 mV
pp
Commutating spikes < 5% (of 5V)
Base load 1.5 A
when a CPU module is inserted
Overvoltage protection with suppressor diode
to protect the modules
Stabilization time < 80 ms after V
in
= 230 V;
<1 ms
after load step (0.5 ->1)*I
rated
Output voltage +15 V
+15 V +/- 0.3 V
Output current
0 to 0.7 A
Ripple < 150 mV
pp
Base load Guaranteed by an inserted module
which requires this voltage
Input voltages
Output voltages
