Subracks
Hardware - SIMADYN D 2-9
Edition 04.2011
2
Output voltage -15 V
-15 V +/- 0.3 V
Output current
0 to 0.6 A
Ripple < 150 mV
pp
Base load Guaranteed by an inserted module
which requires this voltage
Time to establish the output voltages Approx. 200 ms
after the power supply voltage has
been applied
SR6 dimensions in mm
(W x H x D)
225 x 320 x 280
Dimensions of the SP7 power supply
in mm (W x H x D)
45.72 x 233.4 x 220
Weight 4 kg
Radio interference suppression level Limit value class B according to VDE
0871
Ventilation SR6: Natural air cooling
SR6V: Fan on the top panel
Screw/plug-in terminal X1 Phönix,
type MSTB 2.5/4-ST/5,08,
cable cross-section 2.5mm²
Screw/plug-in terminal X2 Phönix,
type MSTB 2.5/3-ST/5,08,
cable cross-section 2.5mm²
General data
