Communications support modules
6-46 Hardware - SIMADYN D
Edition 12.2004
Pin Designation Explanation
1 RS 232:
Ground
For „SS52load“; (for SS52 from edition, approx. 7.97!)
2 RS 232: TxD For „SS52load“: Transmit signal
3
RS485 +
PROFIBUS: Receive- and transmit signal +
(corresponding to data B)
4 RTS Request to send
(to drive an OLM; „1“ when transmitting; as for pin 9)
5 M5EXT External ground; to supply OLMs
6 P5EXT External P5; to supply OLMs
7 RS 232: RxD For „SS52load“: Receive signal
8
RS485 -
PROFIBUS: Receive- and transmit signal -
(corresponding to data A)
9 RTS Request to send
(to drive the OLM; „1“ when transmitting; as for pin 4)
Table 6-8 SS52: Pin assignment of the 9-pin SUB D socket connector X5
6.9.5 Technical data
Dimensions (W x H x D) 70 x 184 x 22 mm
Weight 0.2 kg
The power supply (+5V, +15V and -15V) is established via the 48-pin plug
connector X1 to CS7.
+5 V SS5: max. 0,4 A
SS52: max. 0,7 A
+15 V max. 10 mA
-15 V max. 10 mA
SS52:
General data
Power supply
