CPU module
Hardware - SIMADYN D 3-17
Edition 03.2001
3
3.3 Signal processor module EP3 with IS_x
6DD1645-0AE0
The EP3 module is used for special applications. Especially for fast closed-
loop control and arithmetic operations involving converter-related functions
including the gating unit and fast analog signal processing (digital filter).
The EP3 has a DSP56002 signal processor.
The module is configured in HWConfig (the board is inserted in the
SIMADYN D station).
It includes interfaces to plug-in technology cards IS_1, IS_2 and IS_3, which
can optimally adapt the peripheral hardware to the particular task.
They are also configured in HWConfig
(the module is inserted in the SIMADYN D station).
NOTE
You will find a detailed description and technical data on EP3 in the
following documentation
"Hardware description large drives"
Order No.: 6DD2921-0XH10.
Order No.
Description
IS_1, IS_2 and IS_3
