6.3.2 Supplementary components
The following fiber-optic cable is used for the coupling:
SINEC FIBER OPTIC CABLE standard cable,
assembled in pairs with 4 BFOC connectors
A detailed description of the fiber-optic cable is described in Catalog "SINEC
Industrial Communication Networks, IK 10".
Table 6-1 Fiber-optic cable Order No. and length code
6.3.3 Application information and noise immunity
• The CS1x, CS22 modules may only be used in a force-ventilated
subrack.
• The modules can only be used in SR12.x and SR24.x subracks (C bus
required).
• Before the power supply voltage of a subrack is switched-on (powered-
up), all of the plug connections of the fiber-optic cables involved must be
inserted.
In operation, the plug connectors of the fiber-optic cable coupling
may not be released.
• Master- and slave subracks can be powered-down while in operation
and powered-up again. The coupling is then re-established.
Fiber-optic cable
Order designation
6XV1 820-5B
H
N
T
U
0
1
2
3
4
5
6
7
8
0
1
2
3
4
5
6
7
8
Multiplier 0,1 m
1 m
10 m
100 m
Length code 0.
1.
2.
3.
4.
5.
6.
7.
8.
.0
.1
.2
.3
.4
.5
.6
.7
.8
