Program memory modules / Interface modules
8-6 Hardware - SIMADYN D
Edition 04.2011
8.2.3 Connector assignment X1
Terminal Designation Terminal Designation Terminal Designation
1 Input volt. divider 1 21 GND volt. divider 1 41 Screen volt. divider 1
2 Output " 22 " 42 "
3 Input volt. divider 2 23 GND volt. divider 2 43 Screen volt. divider 2
4 Output " 24 " 44 "
5 Input channel 1 25 GND channel 1 45 Screen channel 1
6 Output " 26 " 46 "
7 Input channel 2 27 GND channel 2 47 Screen channel 2
8 Output " 28 " 48 "
9 Input channel 3 29 GND channel 3 49 Screen channel 3
10 Output " 30 " 50 "
11 Input channel 4 31 GND channel 4 51 Screen channel 4
12 Output " 32 " 52 "
13 Input channel 5 33 GND channel 5 53 Screen channel 5
14 Output " 34 " 54 "
15 Input channel 6 35 GND channel 6 55 Screen channel 6
16 Output " 36 " 56 "
Table 8-2 Connector assignment of X1
