Input/output modules
Hardware - SIMADYN D 5-53
Edition 12.2004
5
5.5.5 Technical data
Insulation group A according to VDE 0110 § 13 Group 2 for 24 V DC,
15 V DC, 5 V DC
Ambient temperature 0 to +55 degrees C and fan operation (force ventil.)
Storage temperature -25 to +70 degrees C
Humidity rating F according to DIN 40050
Altitude rating S according to DIN 40040
Mechanical rating Installed in stationary equipment, which is not
necessarily vibration-free
Packaging system ES 902 C
Dimensions 233.4 mm * 220 mm
Module width 20.14 mm
Installation size 1 slot
Weight 600 g
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V 100 mA
+15 V +14.4 V +15.6 V 490 mA (+ encoder load)
-15 V -15.6 V -14.4 V 75 mA
24 V (external) +15V +30 V 70 mA (+ load of the binary outputs)
No. 2
Version Output with associated ground,
non-floating
Output voltage range -10 V to +10 V
Output current +/- 10 mA
Resolution 12 bits
Monotony 10 bits over the complete temperature range
Absolute accuracy Typ. 9 bits over the complete temperature range
Short-circuit protection to
ground
Yes
No. 4 non-floating
Input voltage 24 V DC rated voltage
For 0 signal -1 V to +6 V or inputs open-circuit
For 1 signal +13 V to +33 V
Input current
For 0 signal 0 mA
For 1 signal 3 mA typ.
Delay time 120 µs
General data
Power supply
Analog outputs,
connector X5
Binary inputs
connector X6
