Input/output modules
5-22 Hardware - SIMADYN D
Edition 12.2004
5.3.3 Connector assignment X7
Connector X7 (50 pin, sub D) connects signals for:
• 4 analog inputs
• 2*8 binary inputs and 2*8 binary outputs
Depending on the required function (signal conversion, LED display)
different interface modules can be connected to the binary inputs and
outputs. If interface modules with signal conversion are used, the SC54
cable must be used:
SC49 cable
max. 2 interface modules, type
SC54 cable
max. 5 interface modules, type
SU10
(25 screw terminals,
no signal conversion)
SB10
SB60
SB61
SB70
SB71
SU12
Table 5-17 Cables and interface modules which can be connected at IT41, connector X7
