Plug-in cables
9-2 Hardware - SIMADYN D
Edition 06.2002
9.1 General information
The ribbon- and round cables are used to connect the following
components:
• CPU modules to interface modules
• input/output- and expansion modules with interface modules
• ITDC expansion module with SITOR thyristor sets
Insulation group According to VDE 0110, degree of pollution 2
Permissible operating peak
voltage
300 V, conductor with respect to ground
Permissible operating voltage 32 V, conductor to conductor
Max. current per cable 1 A
Max. resistance 220 Ohm/km
Cable width (ribbon cable) Core number x 1.27 mm
Table 9-1 General technical data
Description
General technical
data
