Plug-in cables
9-4 Hardware - SIMADYN D
Edition 06.2002
9.2 Cable types
Ribbon cable SC7 10 pin
Application
Connects the 10-pin connector strip of a CPU module
with the 10-pin plug connector strip of an interface
module.
Features Unscreened ribbon cable
2 socket connectors, 10 pin
(1:1) connection, can be inserted from any direction
Cable ends
Plug connectors according to DIN 41651 with strain relief
at both ends.
Length 2 m
Order No. 6DD1684-0AH0
Table 9-3 Ribbon cable SC7
Ribbon cable
SC12
20 pin, twisted pairs
Application
Connects the 20 pin plug connector of an input/output
module with the 20 pin plug connector of an interface
module.
Features
• unscreened ribbon cable
• twisted pairs
• two 20-pin socket connectors
• (1:1) connection
• can be inserted from any direction
Cable ends
Plug connectors according to DIN 41651 with strain relief
at both ends.
Length 2 m
Order No. 6DD1684-0BC0
Table 9-4 Ribbon cable SC12
SC7
SC12
