Input/output modules
5-42 Hardware - SIMADYN D
Edition 12.2004
5.4.7 Technical data
No. of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight Approx. 0.5 kg
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V 420 mA
+15 V +14.4 V +15.6 V 450 mA
-15 V -15.6 V -14.4 V 140 mA
24 V (external) 20 V 30 V 100 mA + binary output currents
No. 4
Integrating analog inputs Differential inputs, floating, V/f conversion
Integration time
• sampling time of the AFC function block or
• the time between 2 positive edges of the
external trigger signal
Input voltage range -10 V to +10 V
Input resistance 470 kOhm
Input filter -3 dB transition frequency : 2 kHz
Resolution Up to 17 bits, depending on the integration time:
13 bits at 1 ms integration time
15 bits at 4 ms integration time
17 bits at 20 ms integration time
Relative accuracy Typ. 14 bits
No. 4
Type Differential inputs, non-floating
Input voltage range -10 V to +10 V
Input resistance 470 kOhm
Input filter -3 dB transition frequency : 1.5 kHz
Resolution 12 bits
Absolute accuracy Typ. 10 bits over the complete temperature
range
Max. conversion time 45 µs.
General data
Power supply
Integrating analog
inputs
Sampling analog
inputs
