Input/output modules
Hardware - SIMADYN D 5-43
Edition 12.2004
5
No. 4
Type Output with associated ground, non-floating
Output voltage range -10 V to +10 V
Output current +/- 10 mA
Resolution 16 bits
Monotony 14 bits over the complete temperature range
Absolute accuracy Typ. 13 bits over the complete temperature
range
Short-circuit protection to
ground
Yes
No. 16 non-floating
Input voltage 24 V DC rated voltage
for 0 signal -1 V to +6 V or open-circuit inputs
for 1 signal +13 V to +33 V
Input current
for 0 signal 0 mA
for 1 signal 3 mA typ.
Delay time
for +24 V input signal
50 µs
No. 16, non-floating
Power supply voltage From external
nominal value 24 V DC
perm. range +20 V to 30 V including ripple
it briefly +35 V, max. 0.5 s
Output current for an 1 signal
nominal current 50 mA (also corresponds to the max. value)
Short-circuit protection Electronically and thermally
Limiting inductive switch-off
voltages
Supply voltage + 1 V
Residual current 20 µA for 0 signal
Signal level
for 0 signal Max. 3 V
for 1 signal Supply voltage - 2.5 V
Switching delay Max. 15 µs
Analog outputs
Binary inputs
Binary outputs
