Input/output modules
Hardware - SIMADYN D 5-35
Edition 12.2004
5
5.4.2 Connector assignment X6
Connector X6 (15-pin, sub D) connects the signals for
• 4 integrating analog inputs
An SU10 interface module can be connected via plug-in cable SC50 ("1:1
connection from the module to the terminals:
IT42
X6
Significance SU10 Connector
designation when
configuring
1 UFC analog input 1+ 1
9 UFC analog input 1- 2 X6A
2 Ground, input 1 3
10 Ground, input 2 4
3 UFC analog input 2+ 5 X6B
11 UFC analog input 2- 6
4 UFC analog input 3+ 7
12 UFC analog input 3- 8 X6C
5 Ground, input 3 9
13 Ground, input 4 10
6 UFC analog input 4+ 11 X6D
14 UFC analog input 4- 12
7 Not connected 13
15 Not connected 14
8 Not connected 15
- Not connected 16 - 26
Table 5-28 Pin assignment IT42, connector X6 and terminal assignment SU10
5.4.3 Connector assignment X7
Connector X7 (25-pin, sub D) connects the signals for
• 4 analog outputs
• 4 analog inputs
An SU10 interface module can be connected via plug-in cable SC51.
Integrating analog
inputs
at X6 with SU10
