Coupling memory module
Hardware - SIMADYN D 4-7
Edition 03.2001
4
4.1.2 Technical data MM11, MM3, MM4
No. of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight MM11: Approx. 0.51 kg
MM3: 0.7 kg
MM4: 0.5 kg
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V MM11: 300 mA
MM3: 600 mA
MM4: 800 mA
+15 V +14.4 V +15.6 V MM3: 50 mA
Back-up battery 2.2 V 3.9 V 20 µA
RDYIN signal output for MM3 and MM4:
Description Values
Voltage max. 60 V DC
Switching current max. 0,5 A
NC contact interrupt time 100 ms
Switching power max. 20 W
General data
Power supply
voltage
System error
relay
