Operator control panel OP2
Hardware - SIMADYN D 10-21
Edition 03.2001
10
No Text Description /cause/ corrective
action
Reference
(Chapter)
- defective BUS cable
24
SYSTEM ERROR
Device not able to function. Critical
faults/errors in the electronics.
General
information
25
INIT. ERROR, NO
MEASURED VALUE
INIT. DATA
Process data haven’t been
completely initialized. OP2 expects
additional process initialization
data. OP2 is not ready. Check the
BUS structure and configuring.
2.3
26
INIT. ERROR, NO
BINARY VALUE INIT.
DATA
Process data haven’t been
completely initialized. OP2 expects
additional process initialization
data. OP2 is not ready. Check the
BUS structure and configuring.
2.3
27
INIT. ERROR,
MEASURED VALUE
INIT. DATA
The initialization data for the
process data are erroneous. The
OP2 is not ready. Check the BUS
structure and configuring
2.3
28
INIT.ERROR, BINARY
VALUE - INIT. DATA
The initialization data for the
process data are erroneous. The
OP2 is not ready. Check the BUS
structure and configuring.
2.3
29
MEASURED VALUE
CHANGE ERROR
Error when changing the process
data. Changing process data in the
VAL/CHANGE mode was
unsuccessful. Repeat the function,
if required check configuring.
1.2.3
30
INITIALIZATION ERROR,
DELAY
Initialization time monitoring
(watchdog) exceeded. OP2 not
ready. Check the BUS structure
and configuring.
2.3.2
31
INTERRUPTION TO THE
HOST CONNECTION
No USS telegrams are received.
Check the BUS connection/cable.
2.2
32
NO BUS CONNECTION,
INCORRECT STATION
ADDRESS
No telegrams with their own
particular station address received.
Configuring error or BUS address
incorrectly set.
2.2 + 1.5.4
33
PRINTER NOT READY
OR NOT CONNECTED
OP 2 does not print. The printer
does not respond. Check the
printer and printer cable.
1.4.6
35
EPROM SAVE
UNSUCCESSFUL
Saving the VAL/CHG/ mode in the
EPROM unsuccessful, check
configuring.
1.2.3
36
TELEGRAM ERROR, NO
BUS CIRCULATION
Check the BUS structure, check
the configuring, master is not
transmitting SCAN telegram with
the OP node number.
2.2
10.6.2 Operating messages
Information texts, alarms (warnings) and fault/error messages are displayed
as operating messages for approximately three seconds, in order to support
the operator resolve problems.
