Siemens SIMADYN D Hardware Manual

Operator control panel OP2
10-22 Hardware - SIMADYN D
Edition 03.2001
No Text Description /cause/ corrective
action
Reference
(Chapter)
1
MEASURED VALUE NOT
INITIALIZED
A process data number V1..V24
was selected which was not
configured in SIMADYN D
1.2
2
FUNCTION NOT
PERMISSIBLE
This function is not permissible in
this mode.
General
information
3
UPPER LIMIT
EXCEEDED
The configured upper limits were
exceeded when a setpoint was
entered or changed.
1.2
4
LOWER LIMIT FALLEN
BELOW
The configured lower limit was
fallen below when entering a
setpoint or changing it
1.2
5
SETPOINT CHANGE
INHIBITED
When selecting the change mode
for a process data, SIMADYN D
did not enable the change.
Presently occupied/changed by
another OP or, was configured as
ACT value.
1.2
6
LAST CHANGE STILL
NOT ACCEPTED
SIMADYN D did not accept the last
process data change. Repeat the
function or check the configuring.
1.2
7
DELAY TIME EXPIRED
SIMADYN D has still not accepted
the actual process data change.
The monitoring time (watchdog)
exceeded. Repeat the function or
check the configuring.
1.2
8
FUNCTION NOT
POSSIBLE
A key was depressed which is not
possible in the current mode.
General info
9
INCORRECT INPUT
An invalid value has been entered General info
11
INITIALIZATION
RUNNING
OP2 waits for general INIT DATA.
OP2 not ready, if required, check
BUS structure and configuring.
2.2.1
12
MEASURED VALUE
INITIALIZATION
OP2 waits for process data
initialization. OP2 not ready, if
required check BUS structure or
configuring.
2.2.1
13
BINARY VALUE
INITIALIZATION
OP2 waits for BINARY VALUE
initialization. OP2 not ready, if
required, check BUS structure or
configuring.
2.2.1
14
NO MEASURED VALUE
INITIALIZED
No process data were initialized
and configured, VAL function is not
possible
1.2
15
NUMBER OF LOST
MESSGES:
Message processing overflow
message. This message is entered
into the message buffer as the
latest message. The most recent
messages overwrite the oldest
messages. The number of lost
messages is incremented until
messages are deleted using DEL.
1.4
17
NO FURTHER
MESSAGES PRESENT
The end of the messages has been
reached when scrolling through the
message buffer.
1.4
