Program memory modules / Interface modules
Hardware - SIMADYN D 8-19
Edition 04.2011
8
8.5.3 Technical data
Mounting system Can be snapped onto mounting rails
Dimensions (W x H x D) 45 x 129 x 160 mm
Weight Approx. 0.32 kg
Nominal power supply voltage
(V
V
)
24 V DC
Permissible range 20 V to 30 V DC
Briefly t<500 ms 1,5 x V
rated
Current drain at the nominal
value
90 mA
The maximun current on connector X3 is 1 A, if this is the power supply
for several interface modules.
Number 8
Nominal input voltage 120 V AC/DC
‘1 signal’ 98 to 132 V
‘0 signal’ 0 to 33 V
1)
Input current (‘1 signal’) max. 3 mA
Insulation voltage Protective separation provided:
- between inputs and outputs
Electrical isolation provided:
- between input circuits
(with respect to one another)
Test voltage 1125V AC
1)
Or open-circuit input
General data
Power supply
Binary inputs
