Siemens SIMADYN D Hardware Manual

Input/output modules
Hardware - SIMADYN D 5-9
Edition 12.2004
5
5.2.2 Connector- and terminal assignment
5.2.2.1 Terminal assignment for SC55
EB11
X5,
X6
Significance SU11
at SC55,
cable end
A
Connector
designation when
configuring
1 Binary output 1 1
2 Binary output 2 2
3 Binary output 3 3
4 Binary output 4 4
5 Binary output 5 5 X5A
6 Binary output 6 6 X6A
7 Binary output 7 7
8 Binary output 8 8
9 External 24 V 9
10 External ground 10
11 Binary output 9 11
12 Binary output 10 12
13 Binary output 11 13
14 Binary output 12 14
15 Binary output 13 15 X5B
16 Binary output 14 16 X6B
17 Binary output 15 17
18 Binary output 16 18
19 External 24 V 19
20 External ground 20
Table 5-6 SU11 terminal assignment for SC55, cable end A
SU11 terminal
assignment at
SC55, end A
