Input/output modules
Hardware - SIMADYN D 5-5
Edition 12.2004
5
The front panel and if relevant, a connector housing, initially have no contact
to the electronics ground of the module. The front panel is only connected to
the electronics ground of the module via the backplane bus connector (L/C
bus connection) and a cable connection, which can be released, between
the backplane bus and the subrack housing.
Further information on EMC and ambient conditions, refer to Section
"General technical data"
5.1.4 Technical data
No. of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight Approx. 0.5 kg
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V 600 mA
+15 V +14.4 V +15.6 V 200 mA
-15 V -15.6 V -14.4 V 200 mA
No. 8
Output voltage, min. - 10 V
Output voltage, max. + 10 V
Output current +/- 10 mA max.
Output current (at +/- 10 V) +/- 5 mA
(recommended to suppress noise)
Resolution 13 bits + sign (corresponds to 1 mV)
Accuracy 14 bits (corresponds to 1 mV)
Short-circuit protection to ground With 56 Ohm resistor
Short-circuit duration 120 s
Total load All outputs simultaneously, each 10 mA
Temperature dependency
Max. 240 μV/degrees
Error
absolute linearity +/-0.6 mV
differential linearity +/- 1 mV
monotony 14 bits (corresponds to 1 mV)
Ground
connections
Other information
General data
Power supply
Analog outputs
