Program memory modules / Interface modules
8-14 Hardware - SIMADYN D
Edition 04.2011
8.4.3 Technical data
Mounting system Can be snapped onto mounting rails
Dimensions (W x H x D) 45 x 129 x 160 mm
Weight Approx. 0.28 kg
ambient temperature for approbations
max. 50° C
Description SIMADYN D
Power supply voltage (V
V
)
at the nominal value
24 V DC
Permissible range 20 V to 30 V DC
Briefly t<500 ms 1,5 x V
rated
Current drain
At the nominal value
1)
20 mA
Maximum current per power supply
cable
400 mA
1)
LED current drain without the load of the system modules
The maximun current on connector X3 is 1 A, if this is the power supply
for several interface modules.
No. 8
Nominal voltage value 24 V DC
Maximum current per channel 30 mA
General data
ambient
temperature
Power supply
Binary signals
