Program memory modules / Interface modules
8-26 Hardware - SIMADYN D
Edition 04.2011
8.6.3 Technical data
Mounting system Housing for snapping onto mounting
rails
Dimensions (W x H x D) 45 x 129 x 160 mm
Weight Approx. 0.32 kg
ambient temperature for approbations
max. 50° C
SIMADYN D Plant/system
side 24 V DC
Plant/system side
48 V DC
Power supply
voltage (V
V
)
24 V DC 24 V DC 48 V DC
Permissible range 20 to 30 V DC 20 to 30 V DC 40 to 60 V DC
Briefly t<500 ms 1.5 x V
rated
1.5 x V
rated
1.5 x V
rated
Current drain at the
nominal value
90 mA 50 mA 50 mA
The maximun current on connector X3 is 1 A, if this is the power supply
for several interface modules. The maximun current on connector X4 is
2 A, if this is the power supply for several interface modules.
Plant/system
side 24 V DC
Plant/system
side 48 V DC
No. 8 8
Input voltage for
‘1 signal’ 13 to 30 V DC 26 to 60 V DC
‘0 signal’ -3 to +6 V
1)
-3 to +12 V
1)
Input current (‘1signal’) 6 mA 6 mA
1)
Or open-circuit input
General data
ambient
temperature
Power supply
Binary inputs
