Communications support modules
6-14 Hardware - SIMADYN D
Edition 12.2004
15-pin sub D socket connector
Pin Signal name Code
1 Collision ( screen ) CI-S
2 Collision ( + ) CI-A
3 Transmit data ( + ) DO-A
4 Receive data ( screen ) DI-S
5 Receive data ( + ) DI-A
6 Power supply ( - ) VC
7 Control signal ( + ) CO-A
8 Control signal ( screen ) CO-S
9 Collision ( - ) CI-B
10 Transmit data ( - ) DO-B
11 Transmit data ( screen ) DO-S
12 Receive data ( - ) DI-B
13 Power supply ( + ) VP
14 Power supply ( screen ) VS
15 Control signal ( - ) CO-B
Housing Overall screen PG
6.2.3 Technical data
No. of slots occupied 1
Dimensions W x H x D [mm] 20.14 x 233.4 x 220
Weight Approx. 0.5 kg
Rated voltage min. max. Typ. current drain
+5 V +4.75 V +5.25 V 2,5 A
+15 V +14.4 V +15.6 V 100 mA without connecting to a
SINEC H1 bus coupler
600 mA with connecting to a SINEC
H1 bus coupler
-15 V -15.6 V -14.4 V Max. 100 mA
SINEC H1 interface
X6
General data
Power supply
