Program memory modules / Interface modules
8-36 Hardware - SIMADYN D
Edition 04.2011
8.8.1 Signals
The 24/48 V DC power supply voltage for the plant/system side signals is
connected at terminal block X4:
Terminal X4 Voltage, plant/system side
2P
2M
+24/48 V
0 V
To connect the power supply use accessory SM11 power supply
connector for interface modules (Order No. 6DD1680-0BB0)
The maximum conductor cross section is 2,5 mm².
To connect the power supply to the terminals X3 and X4 use accessory
SM11 power supply connector for interface modules
(Order No. 6DD1680-0BB0). The maximum conductor cross section on
terminals X3 and X4 is 2,5 mm².
The SIMADYN D power supply is available at the double test socket X5
(G; +):
Double test socket X5 Voltage, SIMADYN D side
+ (1P of X3)
G (1M of X3)
+24 V
0 V
!
WARNUNG Explosion Hazard
No connections are to be made to X5 unless the area is known to be
non-hazardous.
The status of the 8 signals is displayed using a yellow LED for each of
these signals (1...8).
There are two screw connections on terminal strip X2 for each signal:
• Terminals 1 to 8 for binary outputs, 24/48 V DC
• Terminals 51 to 58 as reference point
Power supply,
plant/system side
Connectors
Test socket
Yellow LED
Terminal block for
binary signals
