Program memory modules / Interface modules
8-32 Hardware - SIMADYN D
Edition 04.2011
8.7.3 Technical data
Mounting system Housing can be snapped onto mounting
rails
Dimensions (W x H x D) 45 x 129 x 160 mm
Weight Approx. 0.37 kg
Power supply voltage (V
V
)
nominal value
24 V DC
Permissible range 20 V to 30 V DC
Briefly t<500 ms 1,5 x V
rated
Current drain at the nominal value 150 mA
The maximun current on connector X3 is 1 A, if this is the power supply
for several interface modules.
No. 8
Switching capability of the relay
contacts
120 V AC 2 A
120 V DC 0.4 A
60 V DC 1 A
< 35 V DC 2 A
Switching frequency max 20 Hz
Insulation voltage
Protective separation provided:
- between inputs and outputs
Electrical isolation provided:
- between input circuits
(with respect to one another)
Test voltage 1125V AC
General data
Power supply
Binary outputs
