Siemens SIMADYN D Hardware Manual

Plug-in cables
Hardware - SIMADYN D 9-3
Edition 06.2002
9
Cable overview with connection possibilities
Module Connec
tor
Cable Partial
connector
designation
Cable conversion Interface module which can be
connected
IT41 X6 SC49 A 50 pin to 2*26 pin SU10
B SU10
SC54 A 50 pin to 5*10 pin SU12, SB10, SB70, SB71
B SU12, SB10, SB70, SB71
C SU12, SB10, SB60, SB61
D SU12, SB10, SB60, SB61
E SU12
IT41 X7 SC49 A 50 pin to 2*26 pin SU10
B SU10
SC54 A 50 pin to 5*10 pin SU12, SB10, SB70, SB71
B SU12, SB10, SB70, SB71
C SU12, SB10, SB60, SB61
D SU12, SB10, SB60, SB61
E SU12
IT42 X6 SC50 15 pin to 26 pin. SU10
IT42 X7 SC51 25 pin to 26 pin. SU10
IT42 X8 SC49 A 50 pin to 2*26 pin SU10
B SU10
SC54 A 50 pin to 5*10 pin SU12, SB10, SB70, SB71
B SU12, SB10, SB70, SB71
C SU12, SB10, SB60, SB61
D SU12, SB10, SB60, SB61
E SU12
EB11 X5 SC55 A 40 pin to 2*20 pin SU11
B SU11
SC13 A 40 pin to 4*10 pin SU12, SB10, SB70, SB71
B SU12, SB10, SB70, SB71
C SU12, SB10, SB60, SB61
D SU12, SB10, SB60, SB61
EB11 X6 SC55 A 40 pin to 2*20 pin SU11
B SU11
SC13 A 40 pin to 4*10 pin SU12, SB10, SB70, SB71
B SU12, SB10, SB70, SB71
C SU12, SB10, SB60, SB61
D SU12, SB10, SB60, SB61
EA12 X6 SC12 20 pin to 20 pin. SU11
PM5/6 X5 SC7 10 pin to 10 pin. SU12
ITDC X7 SC17.2 50 pin to 50 pin. SITOR interface
ITDC X7 SC31.2 50 pin to 50 pin. SITOR interface
PM5/6 X4 SC57 Monitor/diagnostics PC
SS4 X5 SC57 Monitor/diagnostics PC
Table 9-2 Modules and the interface modules which can be connected
