Input/output modules
Hardware - SIMADYN D 5-21
Edition 12.2004
5
IT41
X6
Encoder with
tracks displaced
through 90º
Encoder with
forwards/
reverse
tracks
SU 10
at cable
end
B
Connector
designation
when
configuring
42 Encoder ground 1
26 Encoder ground 2
10 Monitoring input,
encoder 1
3
43 Monitoring input,
encoder 2
4
27 Monitoring input,
encoder 3
5
11 Monitoring input,
encoder 4
6
44 Alarm input 1 7
28 Alarm input 2 8
12 Alarm input 3 9
45 Alarm input 4 10
29 Alarm output 1 11
13 Alarm output 2 12
46 Alarm output 3 13
30 Alarm output 4 14
14 Alarm ground 15
47 Ground (de-coupled) Analog outputs 16
31 Ground (de-coupled) Analog outputs 17
15 Analog output 1 18 X6E
48 Ground 19
32 Analog output 2 20 X6F
16 Ground 21
49 Analog output 3 22 X6G
33 Ground 23
17 Analog output 4 24 X6H
50 Ground 25
Table 5-16 Pin assignment IT41, connector X6 and terminal assignment SU10 at SC49,
end B
SU10 terminal
assignment at
SC49, end B
