Input/output modules
5-24 Hardware - SIMADYN D
Edition 12.2004
IT41
X7
Significance SU 10
at SC49,
cable end
B
Connector
designation when
configuring
42 Binary input 6 1
26 Binary input 7 2 X7C
10 Binary input 8 3
43 External P24 voltage 4
27 External ground 5
11 Binary input 9 6
44 Binary input 10 7
28 Binary input 11 8
12 Binary input 12 9 X7D
45 Binary input 13 10
29 Binary input 14 11
13 Binary input 15 12
46 Binary input 16 13
30 External P24 voltage 14
14 External ground 15
47 Reference ground for
differential analog input
16
31 Reference ground for
differential analog input
17
15 Analog input 1+ 18 X7E
48 Analog input 1- 19
32 Analog input 2+ 20 X7F
16 Analog input 2- 21
49 Analog input 3+ 22 X7G
33 Analog input 3- 23
17 Analog input 4+ 24 X7H
50 Analog input 4- 25
Table 5-19 SU10 terminal assignment for SC49, cable end B
SU10 terminal
assignment at
SC49, end B
