Subracks
2-30 Hardware - SIMADYN D
Edition 04.2011
Output voltage -15 V -15 V +/- 0.3 V
Output current 0 to 0.2 A
Ripple < 150 mV
ss
Output voltage +24 V +24 V ( 20-30 V)
Output current
0 to 0.6 A
Time that it takes for the output
voltages to establish themselves
Approx. 200 ms after the power
supply voltage has been applied
Dimensions in mm
(W x H x D)
90.5 x 291 x 168.5
Weight 2 kg
Radio interference suppression
level
Limit value class B acc. to
VDE 0871
Ventilation Natural air cooling
Line supply connection
Screw/plug-in terminal 3 pin
Phönix,
type Front 2,5H
cable cross-section max. 2,5mm²
24V output terminal
Screw/plug-in terminal 2 pin
Phönix,
type Front 2,5H
cable cross-section max. 2,5mm²
General data
