Input/output modules
5-38 Hardware - SIMADYN D
Edition 12.2004
IT42
X8
Significance SU10
at SC49,
cable end
B
Connector
designation when
configuring
42 Binary input 6 1
26 Binary input 7 2 X8C
10 Binary input 8 3
43 External P24 voltage 4
27 External ground 5
11 Binary input 9 6
44 Binary input 10 7
28 Binary input 11 8
12 Binary input 12 9
45 Binary input 13 10 X8D
29 Binary input 14 11
13 Binary input 15 12
46 Binary input 16 13
30 External P24 voltage 14
14 External ground 15
47 Trigger input 1 16
31 Trigger input 2 17
15 Trigger input 3 18
48 Trigger input 4 19
32 Not connected 20
16 Not connected 21
49 Not connected 22
33 Not connected 23
17 External P24 voltage 24
50 External ground 25
Table 5-31 SU10 terminal assignment for SC49, cable end A
SU10 terminal
assignment at
SC49, end B
