Input/output modules
5-40 Hardware - SIMADYN D
Edition 12.2004
IT42
X8
Significance
X8B
SU12 SB10 SB60 SB61 SB70 SB71
37 Binary output 9 1 1/51 12/11/14 1/51
21 Binary output 10 2 2/52 22/21/24 2/52
5 Binary output 11 3 3/53 32/31/34 3/53
38 Binary output 12 4 4/54 42/41/44 4/54
22 Binary output 13 5 5/55 52/51/54 5/55
6 Binary output 14 6 6/56 62/61/64 6/56
39 Binary output 15 7 7/57 72/71/74 7/57
23 Binary output 16 8 8/58 81/82/84 8/58
7 External P24
voltage
9 1P 1P 1P
40 External ground 10 1M 1M 1M
Table 5-34 Terminal assignment, interface module at connector X8, SC54 - cable end B
IT42
X8
Significance
X8C
SU12 SB10 SB60 SB61 SB70 SB71
24 Binary input 1 1 1/51 14,12/11 1,11/51
8 Binary input 2 2 2/52 24,22/21 2,12/52
41 Binary input 3 3 3/53 34,32/31 3,13/53
25 Binary input 4 4 4/54 44,42/41 4,14/54
9 Binary input 5 5 5/55 54,52/51 5,15/55
42 Binary input 6 6 6/56 64,62/61 6,16/56
26 Binary input 7 7 7/57 74,72/71 7,17/57
10 Binary input 8 8 8/58 84,82/81 8,18/58
43 External P24
voltage
9 1P 1P 1P
27 External ground 10 1M 1M 1M
Table 5-35 Terminal assignment, interface module at connector X8, SC54 - cable end C
IT42
X8
Significance
X8D
SU12 SB10 SB60 SB61 SB70 SB71
11 Binary input 9 1 1/51 14,12/11 1,11/51
44 Binary input 10 2 2/52 24,22/21 2,12/52
28 Binary input 11 3 3/53 34,32/31 3,13/53
12 Binary input 12 4 4/54 44,42/41 4,14/54
45 Binary input 13 5 5/55 54,52/51 5,15/55
29 Binary input 14 6 6/56 64,62/61 6,16/56
13 Binary input 15 7 7/57 74,72/71 7,17/57
46 Binary input 16 8 8/58 84,82/81 8,18/58
30 External P24
voltage
9 1P 1P 1P
14 External ground 10 1M 1M 1M
Table 5-36 Terminal assignment, interface module at connector X8, SC54 - cable end D
Terminal
assignment at
SC54, end B
Terminal
assignment at
SC54, end C
Terminal
assignment at
SC54, end D
