Input/output modules
Hardware - SIMADYN D 5-51
Edition 12.2004
5
ITDC
X7 Pin
Designation Connector
designation
for
configuring
1 Screen X7G
2 Screen
3 Fuse monitoring (fault = "L")
4 Screen
5 Zero crossover (L1-L3)
6 Screen
7 +/- I
act
frequency: 60KHz +/- 30KHz
corresponds to +/- 2 I
N
8 Reference voltage, excitation current
setpoint
9 M24 external
10 Pulse. 1.6
11 M24 external
12 Pulse 1.3
13 Screen
14 M24 external
15 Pulse 2.4
16 M24 external
17 Pulse 2.1 X7G
18 V
SYN
(synchronizing voltage) neutral point
19 Excitation current monitoring (fault = "H")
I
E_act
< 3,3 %, I
E_N
= "H")
20 Temperature monitoring (fault = "L")
21 Screen
22 +/- V
AIst
frequency 60KHz +/- 30KHz
corresponds to +/- V
AN
23 Screen
24 +/- I
act
analog +/-10V corresponds to +/- I
N
(only when connecting a SITOR set, for
SE20.1--> 2P24)
25 Screen
26 M24 external
27 Pulse 1.4
28 M24 external
29 Pulse 1.1
30 Pulse 2.2
31 M24 external
32 Pulse 2.5
33 M24 external
34 V
SYN
(L1)
35 Undervoltage monitoring (fault = "L")
36 Screen
37 Zero crossover (L1-L2)
SITOR signals
