Siemens SIMADYN D Hardware Manual

Communications support modules
Hardware - SIMADYN D 6-3
Edition 12.2004
6
The connection between the CS7 support module and the communications
modules is established via the 48-pin socket connectors of the 3 plug-in
receptacle X01, X02 and X03:
Pin A B C
1 P5 P5 L_LOCK
2
A
B1
A
B2
A
B3
3
A
B4
A
B5
A
B6
4
A
B7
A
B8
A
B9
5
A
B10
A
B11
A
B12
6 L_RESET CTCLK
A
B13
7 DB0 DB1 DB2
8 DB3 DB4 DB5
9 DB6 DB7 DB8
10 DB9 DB10 DB11
11 DB12 DB13 DB14
12 DB15 L_DEN L_CSMSB
13 L_INTDPR DT_L_R L_CSLSB
14 L_RDYDPR L_LED1 L_LED2
15 P15 N15 L_INTUHR
16 M5 M5 M5
Interface to the
communications
module
