Communications support modules
6-8 Hardware - SIMADYN D
Edition 12.2004
6.1.2 Communications support module CS8
6DD1662-0AC0
The CS8 module is a support module for the following communication
modules:
• CBP1, CBP2
• CBC, CBD, CBI, CBL
Serial data transfer protocols (CAN, DEVICE-NET, PROFIBUS) can be
implemented using CS8 and the communication modules.
• 2 slots (X01, X02) to accept 2 communication modules (COMBOARDs).
• The special covers supplied must be mounted onto the COMBOARDs, so
that they are electrically connected and grounded, for EMC-, dust
protection- and safety reasons.
• L-bus connection
The connection between the CS8 support module and the communication
modules is established via the 64-pin plug connectors of the 2 slots X01 and
X02:
Pin-
No.
Signal-
name
Pin-
No.
Signal-
name
Pin-
No.
Signal-
name
Pin-
No.
Signal name
A1 N15 A9 D10 A17 M A25 L_BUSY
B1 N15 B9 D11 B17 P5 B25 L_INT_CU_DPR
A2 M A10 D12 A18 A8 A26 L_INT_DPR_CU
B2 M B10 D13 B18 A9 B26 TEMPERATURE
A3 D0 A11 D14 A19 A10 A27 L_DSAVE
B3 D1 B11 D15 B19 A11 B27 ATACHO_DPR
A4 D2 A12 M A20 A12 A28 BTACHO_DPR
B4 D3 B12 SYNC_DNE B20 Excitation B28 P15_OK
A5 D4 A13 NR_TACHO A21 M A29 P24_AUX
B5 D5 B13 A1 B21 P5 B29 M24_AUX
A6 D6 A14 A2 A22 L_RD A30 P15
B6 D7 B14 A3 B22 L_WR B30 P15
A7 M A15 A4 A23 L_CS A31 M
B7 P5 B15 A5 B23 SYNC_TAC B31 M
A8 D8 A16 A6 A24 M A32 SINE
B8 D9 B16 A7 B24 L_RESET B32 COSINE
Order No.
Description
Features
Interface to the
communications
module
