Communications support modules
6-44 Hardware - SIMADYN D
Edition 12.2004
function block @CSPRO and
contact the SIMADYN
Hotline
Check the bus cable and other
bus nodes
Flashing, 1 Hz Initialize the connection to
the associated CPU module
(@CSPRO);
check @CSPRO configuring;
COM database not available
or inactive (during download)
Flashing, 0.5
Hz
- CFC- and COM configuring do
not match;
bus operation possible with
some restrictions
Lit Initialization O.K. Bus operation O.K.
Additional LEDs are available on SS5/SS52; however, they are only visible
when the module is inserted in an adapter card:
LEDs on SS5 Significance for SS5
D1 No function
D2 No function
D3 Off / on:
Flickers / glows:
Not transmitting;
PROFIBUS interface transmitting data
D4 Off / on:
Flickers / glows:
Not receiving;
PROFIBUS interface receiving data
LEDs SS52 Significance for SS52
H1 On PROFIBUS interface operational
Off PROFIBUS interface not operational
6.9.4 Connector assignment X5
PIN Designation Function
LED on SS5
LED on SS52
SS5:
