Program memory modules / Interface modules
Hardware - SIMADYN D 8-39
Edition 04.2011
8
8.8.4 Connector assignment
To connect the interface module to the SIMADYN D / SIMATIC TDC /
S7-400 FM 458- components use cable SC62 or SC64 (for further
informations see the documentation of the SIMADYN D / SIMATIC TDC /
S7-400 FM 458- components).
Terminal Designation
1 Binary output 1
2 Binary output 2
3 Binary output 3
4 Binary output 4
5 Binary output 5
6 Binary output 6
7 Binary output 7
8 Binary output 8
51 0 V, binary output 1
52 0 V, binary output 2
53 0 V, binary output 3
54 0 V, binary output 4
55 0 V, binary output 5
56 0 V, binary output 6
57 0 V, binary output 7
58 0 V, binary output 8
Table 8-9 Assignment of binary outputs of interface module SB71
The minimun conductor cross section for the terminal block X2 is
0,2mm², the maximum conductor cross section is 2,5 mm².
flat connector X1
Binary outputs,
terminal strip X2
Conductor cross
section
