Program memory modules / Interface modules
Hardware - SIMADYN D 8-43
Edition 04.2011
8
8.9.2 Supplementary components
The following cables are required to connect the interface modules to the
modules:
Cable Module Plug connector
SC49 IT41 X6/X7
IT42 X8
SC50 IT42 X6
SC51 IT42 X7
Table 8-11 Modules and signal cables as supplementary components for SU10
Cable Module Plug connector
SC55 EB11 X5
SC55 EB11 X6
SC12 EA12 X6
Table 8-12 Modules and signal cables as supplementary components for SU11
Cable Module Plug connector
SC54 IT41 X6, X7
IT42 X8
SC13 EB11 X5, X6
SC7 PM5 X5
PM6 X5
SC64 FM458-1 DP X2
SC62 EXM438-1 X3
Table 8-13 Modules and signal cables as supplementary components for SU12
Leitungstyp Baugruppen Steckverbinder
SC63 EXM 438-1 X1, X2, X3
Table 8-14 Modules and signal cables as supplementary components for SU13
Cables for
SU10
SU11
SU12
SU13
