Operator control panel OP2
Hardware - SIMADYN D 10-9
Edition 03.2001
10
The user can print-out all of the acquired messages using the PRINT/OLD or
PRINT/ACT keys (the two keys should be simultaneously depressed).
For OLD/PRINT, all of the messages including the presently displayed
message, are printed. For ACT/PRINT, that message is printed, which is
being currently displayed.
The messages are not automatically deleted after having been printed.
Messages are printed using the DEL key.
When parameterizing OP2, it should be specified as to whether messages
should be printed immediately after they have been received in the OP2
(refer to "Parameterizing for the message system processing")
If YES is entered, then the messages are printed-out immediately after the
message telegram has been received. With this type of print-out, there is no
guarantee that the messages are printed-out in the correct chronological
sequence.
Characters 1-40 Characters 41-80
1234567890123456789012345678901234567890123456789012345678901234567890123456789
11.10.94 20:13:44:571 W MOTO R No . 4 HAS SPEED: -999.121234567E+01 RPM
Print control
Deleting messages
Automatic printing
