Subracks
2-18 Hardware - SIMADYN D
Edition 04.2011
X101 to X124 96-pole socket connector DIN 41612 Type C (C bus)
X201 to X224 96-pole socket connector DIN 41612 Type C (L bus)
The L- and C buses are essentially assigned the same.
The signals with grey background are only available at the L bus.
Pin No. Row a Row b Row c
1 5V 5V 5V
2 AUX2 AB20 AB22
3 AUX1 AB21 AB23
4 +15V +15V +15V
5 AUX0 -15V -15V
6 *LOCK *CSPER *CSINI
7 5VEXT 5VEXT *RSERQ
8 Vcc AB12 AB0
9 *BATAL 0V AB1
10 *DSAD AB13 AB2
11 *DSAVE PLC0 AB3
12 AB19 AB14 AB4
13 *OUTDS PLC1 AB5
14 *RESET AB15 AB6
15 *BHE PLC2 AB7
16 *BRQ AB16 AB8
17 *BGIN PLC3 AB9
18 *BGOUT AB17 AB10
19 *BCLR PLC4 AB11
20 *IR0 AB18 DB0
21 *IR1 0V DB1
22 *IR2 DB11 DB2
23 *IR3 0V DB3
24 *RDYIN DB12 DB4
25 *RDY PRIVAT DB5
26 *WR DB13 DB6
27 *RD 0V DB7
28 CLK DB14 DB8
29 *CLK.M 0V DB9
30 *DEN DB15 DB10
31 *HWE RES SBR
32 DT/*R 0V SBT
Signal assignment,
backplane
connector
