Subracks
2-22 Hardware - SIMADYN D
Edition 04.2011
Output voltage 5 V
+5.1 V +/- 0.1 V
Output current
SR12: 0 to 26 A
SR24: 0 to 52 A
Ripple < 50 mV
pp
Commutating spikes < 5% (of 5V)
Base load Guaranteed when a CPU module is
inserted
Overvoltage protection With suppressor diode,
to protect the modules
Stabilization time < 80 ms after U
in
= 230 V;
<1 ms
after a load step (0.5 ->1)*I
rated
Output voltage +15 V
+15 V +/- 0.3 V
Output current
SR12: 0 to 3.3 A
SR24: 0 to 6.5 A
Ripple < 150 mV
pp
Base load Guaranteed by an inserted module
which requires this voltage
Output voltage -15 V
-15 V +/- 0.3 V
Output current
SR12: 0 to 3.0 A
SR24: 0 to 6.0 A
Ripple < 150 mV
pp
Base load Guaranteed by an inserted module
which requires this voltage
SR12 SR24
Dimensions in mm
(W x H x D)
298.5 x 508.5 x 320 542 x 508.5 x 320
Weight 10.5 - 11 kg 16.2 - 17.3 kg
Radio interference suppression level Limit value class B acc. to
VDE 0871
Output voltages
General data
