Siemens SIMATIC ET 200S - 2 RO NO 24-120 VDC;5 A 24-230 VAC;5 A digital electronic module (6 ES7 132-4 HB00-0 AB0)

Digital Electronic Modules
11-76
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
11.18 2RO NO 24--120 VDC/5 A 24--230 VAC/5 A digital
electronic module (6ES7 132-4HB00-0AB0)
Order number
6ES7 132-4HB00-0AB0
Note
If an SELV/PELF low voltage is connected to a channel of the 2RO NO 24--120
VDC/5 A 24--230 VAC/5 A, only one SELV/ PELF low voltage can be connected to
the other channel.
From product level 2 of the 2RO NO 24--120 VDC/5 24--230 VAC/5 A the internal
bridge between terminals 2 and 6 is not installed. If you require this bridge, it can
be replaced by an external bridge between terminals 3 and 7 (see Figure 11-20).
Features
• Digital electronic module with two relay outputs
• Output current 5 A per output
• Rated load voltage up to 120 VDC/230 VAC
• Suitable for solenoids, DC current protection and warning lights
• Potential isolated to power supply
!
Caution
The rated power supply of the 2RO NO 24--120 VDC/5 A 24--230 VAC/5 A is
24 VDC. The 2RO NO 24--120 VDC/5 A 24--230 VAC/5 A must only be in a
potential group with 24 VDC (from the power module).
