Motor Modules Booksize
4.2 Motor Modules with Internal Air Cooling
Equipment Manuel for Booksize Power Modules
4-18 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Table 4-10 Technical specifications for Single Motor Modules booksize (45 to 200 A)
Internal air cooling 6SL3120– 1TE24-5AAx 1TE26-0AAx 1TE28-5AAx 1TE31-3AAx 1TE32-0AAx
Rated current A 45 60 85 132 200
Voltage
Power supply:
DC link voltage
Electronics power supply
V
DC
V
DC
510 – 750
24 (20.4 - 28.8)
Output voltage V
ACrms
0 - 0.67 x DC link voltage
Overvoltage trip threshold
Undervoltage trip threshold
V
DC
V
DC
820 ± 2%
380
Electronics current
consumption at 24 V
A
DC
1.2 1.2 1.5 1.5 1.5
Total power loss
(including electronic losses)
1
W 458.8 618.8 786 1286 2086
Rated output current (l
n
) A
ACrms
45 60 85 132 200
Base load current (I
geund
) A 38 51 68 105 141
Intermittent duty current (l
s6
)
40%
A
ACrms
60 80 110 150 230
Peak current (l
max
) A
ACrms
85 113 141 210 282
DC link busbar current
carrying capacity
A
DC
100 100 200 200 200
24 V busbar current carrying
capacity
A
DC
20 20 20 20 20
Rated power
(with DC link voltage of 600
V
DC
and clock frequency of
4 kHz)
kW 24 32 46 71 107
Max. pulse frequency
without derating
kHz 4 4 4 4 4
Max. pulse frequency with
derating
kHz 16 16 16 16 16
Max. ambient temperature
without derating
°C 40 40 40 40 40
Max. ambient temperature
with derating
°C 55 55 55 55 55
DC link capacitance μF 1175 1410 1880 2820 3995
Efficiency (4kHz) η 0.97 0.97 0.97 0.97 0.97
Sound pressure level dB(A) <65 <65 <60 <73 <73
Cooling method (with fan) Internal fan Internal fan Internal fan Separate
mounted fan
Separate
mounted fan
Cooling air requirement m
3
/h 112 112 160 520 520
Weight kg 9 9 15 21 21
