7.3 24 V DC supply voltage
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7-9
7.3.3 Typical 24-V component power consumption
A separate 24 V power supply must be used for the SINAMICS S120 drive line-up.
The following table can be used to calculate the 24 V DC power supply. The values for
typical current consumption are used as a basis for configuration.
Table 7-7 Overview of 24 V DC current consumption
Component Typical current consumption [A
DC
]
CU320 without load
per digital output
PROFIBUS Teleservice
0.8
0.1
TB30 (without digital outputs)
per digital output
< 0.05
0.1
CBC10 0.1
Active Line Modules
16 kW 1.1
36 kW 1.5
55 kW 1.9
80 kW 2
120 kW 2.5
Smart Line Modules
5 kW 1.0
10 kW 1.3
16 kW 1.1
36 kW 1.5
DRIVE-CLiQ and brake
DRIVE-CLiQ (e.g. motors with DRIVE-CLiQ interface) Typ. 0.25, max. 0.45
Brake (e.g. motor holding brake) Typ. 0.4 to 1.1; max. 2
Single Motor Modules
3 A (+1 x DRIVE–CLiQ; +1 x brake) 0.85
5 A (+1 x DRIVE–CLiQ; +1 x brake) 0.85
9 A (+1 x DRIVE–CLiQ; +1 x brake) 0.85
18 A (+1 x DRIVE–CLiQ; +1 x brake) 0.85
30 A (+1 x DRIVE–CLiQ; +1 x brake) 0.9
45 A (+1 x DRIVE–CLiQ; +1 x brake) 1.2
60 A (+1 x DRIVE-CLiQ; +1 x brake) 1.2
85 A (+1 x DRIVE–CLiQ; +1 x brake) 1.5
132 A (+1 x DRIVE–CLiQ; +1 x brake) 1.5
200 A (+1 x DRIVE–CLiQ + 1 x brake) 1.5
