Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.7 Cooling
Equipment Manuel for Booksize Power Modules
7-32 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7.7 7.7 Cooling
7.7.1 General
The following devices are available as cooling equipment:
• filtered fans
• heat exchangers or
• cooling units.
The decision in favor of one of these methods will depend on the prevailing ambient
conditions and the cooling power required.
The ventilation clearances stated here must be observed. No other components or cables
must be located in these areas.
Caution
If you do not observe the guidelines for installing SINAMICS equipment in the cabinet, this
can reduce the service life of the equipment and result in premature component failure.
You must take into account the following specifications when installing a SINAMICS drive
line-up:
• Ventilation clearance
• Cable routing
• Air guidance, air-conditioner

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
