Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.2 Selection of devices required for operation of SINAMICS
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7-5
7.2.3 Overcurrent Protection by Means of Line Fuses or Circuit-Breakers
The cables for the drive line-up power supply must be protected against overcurrents. NH, D,
and DO-type fuses with a gL characteristic or suitable circuit-breakers can be used for this
purpose.
Note
For use in networks capable of supplying a maximum of 36 kA rms at 480 Vac if the device
is protected by means of the UL-approved (JFHR2) semiconductor safety fuse specified in
the manual.
The devices have to be protected with semiconductor fuses in accordance with the Manual.
The following tables list the requirements regarding line fuses and circuit-breakers for the
Active Line Modules and Smart Line Modules.
Table 7-3 Requirements regarding line fuses and circuit-breakers for Active Line Modules
16 kW 36 kW 55 kW 80 kW 120 KW
I
rated
fuse 35 A 80 A 125 A 160A 250A
I
fuse
0.2s >180 A >360 A >450 A >650 A >865 A
I
fuse
4s >130 A >260 A >350 A >505 A >675 A
I
fuse
10 s >100 A >200 A >250 A >360 A >480 A
I
fuse
240 s >60 A >135 A >200 A >280 A >380 A
Table 7-4 Requirements regarding line fuses and circuit-breakers for Smart Line Modules
5 kW 10 kW 16 kW 36 kW
I
rated
fuse 16 A 35 A 35 A 80 A
I
fuse
0.2s >70 A >100 A >180 A >360 A
I
fuse
4s >50 A >80 A >130 A >260 A
I
fuse
10 s >42 A >65 A >100 A >200 A
I
fuse
240 s >30 A >45 A >60 A >135 A
See catalog D21.2.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
